DeviceMaster Installation and Configuration Guide: 2000594 Rev. F Hardware Installation - 19
Hardware Installation
4. Verify that the Status LED has completed the boot cycle and network connection for the DeviceMaster is
functioning properly using the following table.
Do not connect RS-422/485 devices until the IP address is configured and an appropriate
port interface type has been configured. The default port setting is RS-232.
5. Go to Initial Configuration on Page 33 to configure the DeviceMaster for use.
DM-2202 and DM-2402
(2-Port with Serial Terminal Connectors) LED Descriptions
STATUS
The STATUS LED on the device is lit, indicating you have power and it has completed
the boot cycle.
Note: The Status LED flashes while booting and it takes approximately 15 seconds for
the Bootloader to complete the cycle. When the Bootloader completes the cycle,
the LED has a solid, steady light that blinks approximately every 10 seconds.
LINK If the LINK (green) LED is lit, it indicates a working Ethernet connection.
ACT If the ACT (yellow) LED flashes, it indicates network activity.
Note: For additional LED information, go to the Status LED table on Page 148.
