Condair CP3 - System 3: Supply air humidity control with continuous output limitation

22
– System 3: Supply air humidity control with continuous output limitation
Supply air humidity control (humidity sensor installed in supply air duct) should be used
only where room humidity control is impracticable for technical reasons. Such systems
alwaysrequireaPI-controller.
Thehumiditysensor(A1)islocatedinthesupplyairductafterthesteamdistributionpipe.The
humiditysensor(A2)forthecontinuousoutputlimitationislocatedinthesupplyairductbefore
thesteamdistributionpipe.SuchasystemrequiresaPI-controllerwiththeoptiontoconnecta
second humidity sensor.
A1/2 humiditysensor
B1 ventilationinterlock
B2 airowmonitor
B3 safetyhumidistat
PI
I
 InternalPIcontroller
PI
E
 ExternalPIcontroller
Y inputsignalfromA1
Z inputsignalfromA2
Which humidity control system for which application?
Application Location of the humidity sensor
room or exhaust air duct supply air duct
Airconditioningsystemswith:
–supplyairportionupto33% System 1 System 1
–supplyairportionupto66% System 1 or 2 System 2 or 3
–supplyairportionupto100% System 2 System 3
– supply air humidity control — System 3
Directroomhumidication System 1 —
Please contact your Condair supplier, if your application meets the following conditions:
– Humidicationofsmallroomsupto200m
3
– Airconditioningsystemswithahighnumberofairexchanges
– Systemswithvariableairvolumeow
– Testfacilitieswithextremecontrolaccuracyrequirements
– Rooms with a high variation in max. steam capacity
– Systemswithtemperatureuctuations
– Coldroomsandsystemswithdehumidication
