23
Input signals
Control with external controller Control with internal PI controller
Control signals Humidity sensor signals
0...5VDC(Potentiometer135Ω...10kΩ) 0...5VDC (Potentiometer135Ω...10kΩ)
1...5VDC 1...5VDC
0...10VDC 0...10VDC
2...10VDC 2...10VDC
0...16VDC 0...16VDC
3.2...16VDC 3.2...16VDC
0...20mA 0...20mA
4...20mA 4...20mA
Humidistat(24VOn/Off)
