CPI COTI - Linea

Secon 9 - Dispense Pipes
9.2 LINEA
There are three sizes of pipes used of which 1 & 3 can be replaced by the Operator:
 CoEx® Espresso Brewer = 4mm white silicone
 Hot water = 8mm grey silicone
 Mixing bowls = 6mm grey silicone
1
3
2
To replace pipes
1. Open cabinet door
2. Using the above informaon about pipe size, connect the pipes to the dispense
head.
3. The pipes should be cut to such lengths so that they are not too taut and also the
pipe doesn’t sag below the delivery head
