11.6 I/O Board - COTI
The input/output board is located at the top right hand side of the machine. It is mounted
onto the rear of the cabinet and can be accessed by removing the ingredient canisters and
the RH boiler cover.
Note: When doing any checks around this area be aware that there are high voltages
present.
11.7 I/O Board - LINEA
The input/output board is located in the boom right hand side of the machine. It is
mounted on the right hand side panel and can be accessed by removing back panel,
releasing mounng screws from the extract fan and power supply unit and moving them
to the right.
Note: When doing any checks around this area be aware that there are high voltages
present
