CPI COTI - Atlas H Board Connections - COTI

Secon 11 - Electrical / Electronic Diagrams
Technical Manual
11.4 Atlas H Board Connecons - COTI
The diagram below and table opposite illustrate the connecons between the control, IRDA
and LED boards.
COTI - LED/IRDA PCB
COTI - LED DRIVER PCB
LED CONTROL/SPI
DOOR
SWITCH
CASHLESS
137
