CPI COTI - USB Stick Content

Secon 4 - Customising the User Interface
4.4 USB Stick Contents
The images and videos saved on the USB sck must be a parcular size, in the correct
format and be located in the right le path. These are detailed below:
4.4.1 COTI Machines
Image type Size in pixels
(W) (H)
File
format
File path
Background icon 1080 x 1045 .png atlas/product_library/background_pictures
Large icon 750 x 1006 .png atlas/product_library/large_product_images
Small icon 190 x 162 .png atlas/product_library/small_product_images
Video 1080 x 1045 .webm atlas/product_library/video
Standby - Image 1080 x 1920 .png/.jpeg atlas/screens
Standby - Video 1080 x 1045 .webm atlas/screens
End of Vend - Image 1080 x 1045 .png/.jpeg atlas/product_library/generic
End of Vend - Video 1080 x 1045 .webm atlas/product_library/generic
Operator Manuals - .html5 atlas/manuals
4.4.2 LINEA Machines
It is important there is no text or key features within the top 350 or bottom 250
pixels as they will not be seen.
Image type Size in pixels
(W) (H)
File
format
File path
Background icon 1280 x 640 .png atlas/product_library/background_pictures
Large icon 547 x 735 .png atlas/product_library/large_product_images
Small icon 120 x 118 .png atlas/product_library/small_product_images
Video 1280 x 640 .webm atlas/product_library/video
Standby - Image 1280 x 800 .png/.jpeg atlas/screens
Standby - Video 1280 x 585 .webm atlas/screens
End of Vend - Image 1280 x 640 .png/.jpeg atlas/product_library/generic
End of Vend - Video 1280 x 640 .webm atlas/product_library/generic
Operator Manuals 1280 x 800 .html5 atlas/manuals
Be aware of the Touch to Start buon (and language ags where used) when preparing
standby screens or videos.
26
