Technical Manual
Index
Secon 1 - Machine Specicaons
1.1 Specicaons - COTI ............................................................................. 1
1.2 Specicaons - LINEA ........................................................................... 2
1.3 Water Filter .......................................................................................... 2
1.4 External Features - COTI ....................................................................... 3
1.5 External Features - LINEA ..................................................................... 4
1.6 Internal Features - COTI ........................................................................ 5
1.7 Internal Features - LINEA ...................................................................... 6
Secon 2 - Installaon
2.1 Sing Your Machine .............................................................................. 7
2.2 Connecng the Water Supply ............................................................... 8
2.3 Connecng the Electrical Supply .......................................................... 9
2.4 Commissioning Procedure .................................................................... 11
2.5 Cup Drop Unit Set Up ........................................................................... 14
Secon 3 - Navigaon and Programming Mode
3.1 Service Menu Entry - COTI .................................................................... 15
3.1 Service Menu Entry - LINEA .................................................................. 16
3.3 Program Entry ...................................................................................... 17
3.4 Navigang through the Menu Display .................................................. 17
3.5 Entering or Updang Parameters ......................................................... 18
Secon 4 - Customising the User Interface
4.1 Images .................................................................................................. 21
4.2 Image Locaons / Screens - COTI ......................................................... 22
4.3 Image Locaons / Screens - LINEA ....................................................... 24
4.4 USB Sck Content ................................................................................. 26
4.5 Copy USB Sck Content ........................................................................ 27
4.6 Select the Images for Display ............................................................... 28
4.7 Remove Content from Machine ........................................................... 30
4.8 Edit Product Name and Descripon ..................................................... 31
4.9 Congure Generic Content ................................................................... 33
4.10 Standby Screen ................................................................................... 33
