Chapter 4
Web Configuration & Operation
4.13 MAC Table
The “MAC Table” menu contains configuration and status sub menu. Select the configuration page to set up detailed
configuration
4.13.1 Configuration
Disable Automatic Aging: Learned MAC addresses will appear in the table permanently.
Aging Time: Set up the aging time for a learned MAC to be appeared in MAC learning table. The allowed range
is 10 to 1000000 seconds.
MAC Learning Table: Three options are available on each port.
Auto: On a given port, learning is automatically done once unknown SMAC is received.
Disable: Disable MAC learning function.
Secure: Only static MAC entries listed in “Static MAC Table Configuration” are learned. Others will be dropped.
Note: Make sure that the link used for managing the switch is added to the Static Mac Table before changing to secure
learning mode, otherwise the management link is lost and can only be restored by using another non-secure port or by
connecting to the switch via the serial interface.
Static MAC Table Configuration: This table is used to manually set up static MAC entries. The total entries that can be
entered are 64.
VLAN ID: Specify the VLAN ID for this entry.
MAC Address: Specify the MAC address for this entry.
Port Members: Check or uncheck the ports. If the incoming packet has the same destination MAC address as the
one specified in VID, it will be forwarded to the checked port directly.
