4.6.1.8 RMON
4.6.1.8.1 RMON Statistics Configuration
Remote monitoring is a standard specification that enables various network monitors to exchange network monitoring
data. RMON provides the user with more freedom in selecting networking monitoring probes that meet their particular
networking needs.
ID: Indicates the index of the entry. The range is from 1 to 65535.
Data Source: Indicates the port ID which wants to be monitored. If in stacking switch, the value must add 1000*(switch
ID-1), for example, if the port is switch 3 port 5, the value is 2005.
Click the “Add New Entry” button to add a new entry.
Click the “Delete” button to remove a newly-inserted entry or select the checkbox to remove a saved entry during the
next save.
Click the “Save” button to save settings or changes.
Click the “Reset” button to restore changed settings to the default settings.
4.6.1.8.2 RMON History Configuration
RMON History Configuration is to collect statistics on a physical interface to monitor network utilization, packet types,
and errors. A RMON historical record can also be used to monitor intermittent problems.
ID: Indicates the index of the entry. The range is from 1 to 65535.
Data Source: Indicates the port ID which wants to be monitored. If in stacking switch, the value must add 1000*(switch
ID-1), for example, if the port is switch 3 port 5, the value is 2005
Interval: Indicates the polling interval. By default, 1800 seconds is specified. The allowed range is 1~3600 seconds.
Buckets: The number of buckets requested for this entry. By default, 50 is specified. The allowed range is 1~3600.
Buckets Granted: The number of buckets granted.
Click the “Add New Entry” button to insert a new entry to the list.
Click the “Delete” button to remove a newly-inserted entry or select the checkbox to remove a saved entry during the
next save.
Click the “Save” button to save settings or changes.
Click the “Reset” button to restore changed settings to the default settings.
