QoS class/DP level: Show the mapping options for QoS class values and DP levels (drop precedence).
PCP: Remarks matching egress frames with the specified Priority Code Point (or User Priority) value. (Range: 0-7; Default:
0)
DEI: Remarks matching egress frames with the specified Drop Eligible Indicator. (Range: 0-1; Default: 0)
4.19.6 Port DSCP
Port: List the number of each. “All” settings apply to all ports.
Ingress Translate: Select the checkbox to enable ingress translation of DSCP values based on the selected classification
method.
Ingress Classify: Select the appropriate classification method:
Disable: No ingress DSCP classification is performed.
DSCP=0: Classify if incoming DSCP is 0.
Selected: Classify only selected DSCP for which classification is enabled in DSCP Translation table
All: Classify all DSCP.
Egress Rewrite: Configure port egress rewriting of DSCP values.
