4.12.6 Port Statistics
Global Counters
Total Neighbours Entries Added: Shows the number of new entries added since the switch was rebooted, and for which
the remote TTL has not yet expired.
Total Neighbors Entries Deleted: The number of LLDP neighbors which have been removed from the LLDP remote
systems MIB for any reason.
Total Neighbors Entries Dropped: The number of times which the remote database on this switch dropped an LLDPDU
because the entry table was full.
Total Neighbors Entries Aged Out: The number of times that a neighbor’s information has been deleted from the LLDP
remote systems MIB because the remote TTL timer has expired.
LLDP Statistics Local Counters
Local Port: The port number.
Tx Frames: The number of LLDP PDUs transmitted.
Rx Frames: The number of LLDP PDUs received.
Rx Errors: The number of received LLDP frames with some kind of error.
Frames Discarded: The number of frames discarded because they did not conform to the general validation rules as well
as any specific usage rules defined for the particular Type Length Value (TLV).
TLVs Discarded: Each LLDP frame can contain multiple pieces of information, known as TLVs. If a TLV is malformed, it is
counted and discarded.
TLVs Unrecognized: The number of well-formed TLVs, but with an unknown type value.
Org. Discarded: The number of organizational TLVs discarded.
Age-Outs: Each LLDP frame contains information about how long the LLDP information is valid (age-out time). If no new
LLDP frame is received within the age-out time, the LLDP information is removed, and the Age-Out counter is
incremented.
