4.19.11 Storm Control
Storm Control is used to keep a network from downgraded performance or a complete halt by setting up a threshold for
traffic like broadcast, unicast and multicast. When a device on the network is malfunctioning or application programs are
not well designed or properly configured, storms may occur and will degrade network performance or even cause a
complete halt. The network can be protected from storms by setting a threshold for specified traffic on the device. Any
specified packets exceeding the specified threshold will then be dropped.
Enable: Enable Unicast storm, Multicast storm or Broadcast storm protection.
Rate (pps): Select the packet threshold. The packets received exceed the selected value will be dropped.
4.20 Mirroring
Port to mirror: Select the mirror port to which either source (rx) or destination (tx) traffic will be mirrored. Or disable
port mirroring function.
Port: The port number. “All” rules apply to all ports.
Mode: There are four modes that can be used on each port.
Disabled: Disable the port mirroring function on a given port.
Rx only: Only frames received on this port are mirrored on the mirror port.
Tx only: Only frames transmitted on this port are mirrored on the mirror port.
Enable: Both frames received and transmitted re mirrored on the mirror port.
