V2 Reports Received: The number of Received V2 Reports.
V2 Leaves Received: The number of Received V2 Leaves.
Router Port
Port: The port number.
Status: Indicate whether a specific port is a router port or not.
4.11.1.5 Groups Information
VLAN ID: Display the VLAN ID of the group.
Groups: Display the group address.
Port Members: Ports that belong to this group.
4.11.1.6 IPv4 SFM Information
VLAN ID: Display the VLAN ID of the group.
Groups: Display the IP address of a multicast group.
Port: The switch port number.
Mode: The filtering mode maintained per VLAN ID, port number and group address.
Source Address: The source IP address available for filtering.
Type: Display either Allow or Deny type.
Hardware Filter/Switch: Indicates whether the data plane destined to the specific group address from the source IPv4
address can be handled by the chip or not.
