4.6.2.7 AAA
4.6.2.7.1 Configuration
Common Server Configuration
Timeout: The time the switch waits for a reply from an authentication server before it retransmits the request.
Deadtime: Deadtime is the period during which the switch will not send new requests to a server that has failed to
respond to a previous request. This will stop the switch from continually trying to contact a server that it has already
determined as dead. Setting the Deadtime to a value greater than 0 (zero) will enable this feature, but only if more than
one server has been configured. The allowed deadtime range is between 0 to 1440minutes.
RADIUS Authentication Server Configuration
Enabled: Select the checkbox to enable this authentication server configuration.
Hostname: The hostname or IP address for the RADIUS authentication server.
Port: The UDP port to be used on the RADIUS server for authentication.
Key: Specify the secret key up to 63 characters. This is shared between the RADIUS sever and the switch
RADIUS Accounting Server Configuration
Enabled: Select the checkbox to enable this accounting server configuration.
Hostname: The hostname or IP address for the RADIUS accounting server.
Port: The UDP port to be used on the RADIUS server for accounting.
Key: Specify the secret key up to 63 characters. This is shared between the RADIUS sever and the switch
TACACS+ Authentication Server Configuration
Enabled: Select the checkbox to enable this TACACS+ authentication server configuration.
