neighbour devices. Details such as port description, system name, system description, system capabilities, management
address can be sent and received on this device.
The “LLDP” menu contains the following sub menus. Select the appropriate menu to set up detailed configurations.
4.12.1 Configuration
LLDP Parameters
Tx Interval: Specify the interval between LLDP frames are sent to its neighbours for updated discovery information. The
valid values are 5~32768 seconds. The default is 30 seconds.
Tx Hold: This setting defines how long LLDP frames are considered valid and is used to compute the TTL. Valid range is
2~10 times. The default is 4.
Tx Delay: Specify a delay between the LLDP frames that contain changed configurations. Tx Delay cannot be larger than
1/4 of the Tx interval value. The valid values are 1 - 8192 seconds.
Tx Reinit: Specify a delay between the shutdown frame and a new LLDP initialization. The valid values are 1~10 seconds.
LLDP Port Configuration
Port: The port number. “All” settings apply to all ports.
Mode: Select the appropriate LLDP mode.
Disabled: LLDP information will not be sent and LLDP information received from neighbours will be dropped.
Enabled: LLDP information will be sent and LLDP information received from neighbours will be analyzed.
Rx Only: The switch will analyze LLDP information received from neighbours.
Tx Only: The switch will send out LLDP information but will drop LLDP information received from neighbours.
