4.16.2 Port Isolation
Private VLAN is used to group ports together so as to prevent communications within PVLAN. Port Isolation is used to
prevent communications between customer ports in a same Private VLAN. The port that is isolated from others cannot
forward any unicast, multicast or broadcast traffic to any other ports in the same PVLAN.
Port Number: Select the checkbox if you want a port or ports to be isolated from other ports.
4.17 VCL
The “VCL” menu contains the following sub menus.
4.17.1 MAC-based
MAC-based VLAN configuration page is to set up VLANs based on source MAC addresses. When ingress untagged frames
are received by a port, source MAC address is processed to decide which VLAN these untagged frames belong. When
source MAC addresses does not match the rules created, untagged frames are assigned to the receiving port’s native
VLAN ID (PVID).
4.17.1.1 Membership Configuration
MAC Address: Indicate the source MAC address. Please note that the source MAC address can only map to one VLAN ID.
VLAN ID: Map this MAC address to the associated VLAN ID.
Port Members: Ports that belong to this VLAN.
Click the “Add New Entry” button to insert a new entry to the list.
Click the “Delete” button to remove a newly-inserted entry or select the checkbox to remove a saved entry during the
next save.
Click the “Save” button to save settings or changes.
