Port: The port number. “All” rules apply to all ports.
Enabled: Select the checkbox to enable EEE function on a port. By default, all ports (except Fiber port) are enabled with
EEE function.
EEE Urgent Queues: It is possible to minimize the latency for specific frames, by mapping the frames to a specific queue
(done with QOS), and then mark the queue as an urgent queue. When an urgent queue gets data to be transmitted, the
circuits will be powered up at once and the latency will be reduced to the wakeup time. Queues set will activate
transmission of frames as soon as data is available. Otherwise the queue will postpone transmission until a burst of
frames can be transmitted.
4.4 Thermal Protection
This page allows the user to inspect and configure the current setting for controlling thermal protection. Thermal
protection is used to protect the chip from getting overheated.
When the temperature exceeds the configured thermal protection temperature, ports will be turned off in order to
decrease the power consumption. It is possible to arrange the ports with different priorities. Each priority can be given a
temperature at which the corresponding ports shall be turned off.
4.4.1 Configuration
