Illustration of two-inlet cartridge
ba
ck
The illustration below shows the locations and gives brief descriptions of the parts on
the back of the cartridge.
Part Description
1
Cartridge inlets with Luer fittings to connect to syringes
2 Cartridge outlet
3 System description
3.
3 Microfluidic cartridges
3.3.2 Two-inlet cartridges
NanoAssemblr Ignite and Ignite+ Operating Instructions NIN1134 AA 25
