5.1.1 Syringe selection
In
troduction
It is important to correctly set the size and brand of syringe in the parameters to
achieve accurate mixing results. Flow rate control is based on the syringe dimensions
that are included in the software.
IMPORTANT
The syringe size and manufacturer chosen in the parameters must
match the syringe used during a run. Using a different syringe than
the one selected in the parameters impacts particle characteris-
tics due to the resulting incorrect flow rates and flow ratios.
Syringe sizes
Wh
en creating a recipe or starting a quick run, it is possible to select the syringe size
and type by selecting from a drop-down menu.
Tip:
Use the smallest syringe that can accommodate the dispensed volume,
be
cause smaller syringes usually reach the target flow rate faster and
require a smaller volume of start waste.
The table below shows the range or values available for each syringe channel for the
di
fferent instruments.
Instrument
Syringe size
L syringe C syringe R syringe
Ignite Up to 30 mL Up to 10 mL Up to 10 mL
Ignite+ Up to 30 mL Up to 30 mL Up to 30 mL
Update available syringe types
Th
e available syringe types are shown in a drop down menu when editing run parame-
ters. Follow the instructions below to update which syringes are shown in the param-
eter settings during a Quick Run or Recipe procedure.
Step Action
1 From the main menu, tap Se
ttings.
2 Tap Syringes.
R
esult:
A list of compatible syringe brands and sizes are displayed. The syringes are
grouped by brand. Each syringe is identified by a two-letter code for the
brand and the syringe volume.
5 Preparation
5.
1 Parameters
5.1.1 Syringe selection
NanoAssemblr Ignite and Ignite+ Operating Instructions NIN1134 AA 57
