3.4.1 Main menu
Ov
erview
The operation and user interface is identical for the Ignite and Ignite+ instruments.
Both instruments have a touchscreen user interface mounted on the front of the main
instrument.
The illustration below shows the main menu on the instrument.
Part Name Description
1 Information bar
Includes menu title, and current date and time
2 Heater control
i
c
on
Shows the status of the heating system
3 Cartridge indicator
Shows the status of the cartridge in the instru-
m
e
nt
4
Recipes
Enables user to create, edit, and store formula-
ti
ons providing convenient access to frequently
used formulations
