3.5.2 Syringe extenders
Syr
inge extenders can be used to extend the overall length of certain syringes that are
too short to use in the Ignite and Ignite+ systems. To use the syringe extender, the
flange of the syringe plunger is inserted into a slot in the syringe extender and the
syringe is secured with a fastening screw. The illustrations below shows the parts of a
syringe extender.
Part Description
1 Slot to insert the flange of the syringe plunger
2 Slot to insert the fastening screw
3 Fastening screw to secure the syringe
Syringe extenders must be used with the following syringe manufacturers and sizes:
• B B
raun Injekt syringes, 2 mL
• Terumo syringes, 2.5 mL
See Section 9.5 Ordering information, on page 130 for more information.
