3.3.2 Two-inlet cartridges
In
troduction
The NxGen cartridge combines reagents from the C and R channels through the mixer
and delivers the mixed fluid to the collection tubes.
Illustration of two-inlet cartridge
front
The illustrations below show the locations and gives brief descriptions of the parts on
the front of the cartridge.
2
3
1
Part Description
1 Cartridge inlets
2 Mixer geometry
3 Cartridge outlet
