D-Link DWC-2000 User Manual 109
Section 4 - Advanced WLAN Conguration
Synchronize Peer Group
Path: Wireless > Peer Group > Peer Status
Synchronize the settings among the peer group.
1. Click Wireless > Peer Group > Peer Status. Peer Status List will appear
2. Click Start Sync for All Peers to synchronize the settings to all controllers, or synchronize one of the
peer group by right-clicking Start Sync.
AP Proles
Enable this eld to include all AP proles in the conguration that the controller
pushes to its peers. The AP prole includes the general AP settings, such as the
hardware type, Radio settings, SSID Proles, and QoS settings.
MAC Authentication DB
Enable this eld to include the MAC Authentication Database in the conguration
that the controller pushes to its peers.
Captive Portal
Enable this eld to include the Captive Portal information in the conguration that
the controller pushes to its peers.
RADIUS Client
Enable this eld to include the Client RADIUS information in the conguration that
the controller pushes to its peers.
Controller Provisioning Mode
Enable this eld to send and receive provisioning messages. As a security feature, you
can disable this option.
Mutual Authentication Mode
Select Enable to require mutual authentication on the wireless network. When
Disable is selected, mutual authentication is not required.
Changing this parameter on one controller automatically updates the conguration
on all other controllers in the cluster and all managed APs in the cluster.
When this eld is enabled, switch provisioning must be enabled in order for new
controllers to be added to the cluster. If controller provisioning is disabled, the cluster
will not accept certicates from a new controller.
Unmanaged AP
Reprovisioning Mode
Enable to allow access points to accept provisioning information when not managed
by a controller.
