D-Link DWC-2000 User Manual 244
Section 8 - Maintenance
2. Set the security level.
noAuthnoPriv: only requires a username match for authentication
authNoPriv: Provides authentication based on the MD5 or SHA algorithms.
authPriv: Provides authentication based on the MD5 or SHA algorithms as well as encryption
privacy with the DES 256-bit standard.
3. Click Save.
2. Click Add SNMP Trap.
3. Complete the information on elds (refer to the table below).
4. Click Save.
Congure SNMP Trap List
1. Go to Maintenance > Management > SNMP > SNMP Trap List tab.
Field Description
IP Address The IP Address of the SNMP trap agent.
Port
The SNMP trap port of the IP address to which the trap messages will
be sent.
Community
The community string to which the agent belongs. Most agents are
congured to listen for traps in the Public community.
Authentication Type The SNMP version used by the trap agent. The choices are v1, v2c, or v3.

Table of Contents

Other manuals for D-Link DWC-2000

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the D-Link DWC-2000 and is the answer not in the manual?

D-Link DWC-2000 Specifications

General IconGeneral
Security algorithms802.1x RADIUS, WPA, WPA2
Data transfer rate1 Gbit/s
USB 2.0 ports quantity2
Ethernet LAN (RJ-45) ports4
Input voltage100 - 240 V
Input frequency50 - 60 Hz
Power consumption (typical)26.95 W
Storage temperature (T-T)-20 - 70 °C
Operating temperature (T-T)0 - 40 °C
Operating relative humidity (H-H)5 - 95 %
Compatible productsDWL-8610AP, DWL-8600AP, DWL-6600AP, DWL-3600AP, DWL-2600AP
CertificationFCC Class A, CE Class A, C-Tick, IC, cUL, LVD
Package depth504 mm
Package width444 mm
Package height110 mm
Package weight5846 g
Pallet width1200 mm
Pallet length1100 mm
Pallet height (air)1095 mm
Pallet height (sea)2055 mm
Pallet gross weight (air)250560 g
Quantity per pallet (air)36 pc(s)
Shipping (inner) case width396 mm
Shipping (inner) case height480 mm
Shipping (inner) case length526 mm
Shipping (inner) case weight18755 g
Shipping (inner) case net weight17538 g
Number of cartons per pallet (air)12 pc(s)
Quantity per shipping (inner) case3 pc(s)
Harmonized System (HS) code85176990
Weight and Dimensions IconWeight and Dimensions
Weight3720 g
Dimensions (WxDxH)440 x 310 x 44 mm
