D-Link DWC-2000 User Manual 133
Section 5 - Advanced Network Conguration
MultiVLAN Subnets
Path: Network > VLAN > VLAN Settings
Each VLAN can be assigned a unique IP address and subnet mask for the virtually isolated network. Unless you
enabled inter-VLAN routing for the VLAN, the VLAN subnet determines the network address on the LAN that can
communicate with the devices that correspond to the VLAN.
To view and edit the available multi-VLAN subnets:
1. Go to Network > VLAN > VLAN Settings.
2. To edit a multi-subnet VLAN, right-click the VLAN and click Edit.
