Section 7 - Viewing Status and Statistics
Path: Status > Wireless Information > WDS Groups Status > WDS Group AP Status
The WDS AP Group Status page displays detailed information about the congured APs and links in the WDS
Group. From this page, you can also send a new password to group members.
Field Description
ID Unique number that identies the WDS AP group.
Congured AP Count Number of APs congured in this WDS AP group.
Connected AP Count
Number of APs managed by the controller that are members of this WDS AP
Group. This number is the sum of the Connected Root APs and Connected
Satellite APs.
Source AP Count
Number of Root APs currently being managed by the controller that are
members of this WDS AP Group.
Destination AP Count
Number of Satellite APs currently being managed by the controller that are
members of this WDS AP Group.
Source Bridge AP MAC
MAC Address of the device elected as the Spanning Tree Root Bridge. If
spanning tree is disabled this value is 00:00:00:00:00:00.
Source Device Type
The type of device elected as the Spanning Tree Root bridge:
• None (STP is disabled)
• Root AP
• Satellite AP
• External Device (STP Root is not one of the APs)
Cong WDS Link Count Number of congured bidirectional links in the WDS AP Group.
Detect WDS Links Count
Number of WDS links detected in the system. APs on both sides of the link
must detect each other in order for the link to be counted.
WDS Group AP Status
