D-Link DWC-2000 User Manual 223
Section 7 - Viewing Status and Statistics
Associated Clients Global Status
Path: Status > Wireless Information > Associated Clients > Global Status
This page shows statistic information about all the clients which are connected through managed AP.
Field Description
Total Clients
Total number of clients in the database. This total includes clients with an
Associated, Authenticated, or Disassociated status.
Authenticated Clients
Total number of clients in the associated client database with an Authenticated
status.
802.11a Clients Total number of IEEE 802.11a-only clients that are authenticated.
802.11b/g Clients Total number of IEEE 802.11b/g-only clients that are authenticated.
802.11n Clients
Total number of clients that are IEEE 802.11n capable and are authenticated.
These include IEEE 802.11a/n, IEEE 802.11b/g/n, 5 GHz IEEE 802.11n, 2.4GHz
IEEE 802.11n.
802.11ac Clients Total number of IEEE 802.11ac-only clients that are authenticated.
Max Associated Clients
Maximum number of clients that can associate with the wireless system.
This is the maximum number of entries allowed in the Associated Client
database.
Detected Clients Number of wireless clients detected in the WLAN.
Max Detected Clients
Maximum number of clients that can be detected by the controller. The
number is limited by the size of the Detected Client Database.
Max Pre-auth History Entries
Maximum number of Client Pre-Authentication events that can be recorded
by the system.
Total Pre-auth History Entries Current number of pre-authentication history entries in use by the system.
Maximum Roam History Entries
Maximum number of entries that can be recorded in the roam history for all
detected clients.
Total Roam History Entries Current number of pre-authentication history entries in use by the system.
