D-Link DWC-2000 User Manual 173
Section 6 - Securing Your Network
3. Complete the elds in the table below and click Save.
Importing Users
Path: Security > Authentication > User Database > Get User DB
A faster alternative to adding individual users is to import users from a CSV-formatted le.
1. Click Security > Authentication > User Database > Get User DB.
2. Click the Browse button.
3. In the Choose File dialog box, navigate to the location of the CSV le, and then click the le.
4. Click Open and then click Upload.
Field Description
User Name
Enter a unique name for this user. The name should allow you to easily identify this user
from others you may add.
First Name Enter the rst name of the user.
Last Name Enter the last name of the user.
Select Group Select the captive portal group to which this user will belong.
Password
Enter a case-sensitive login password that the user must specify at the login prompt to
access the web management interface. For security, each typed password character is
masked with a dot (•).
Conrm Password
Enter the same case-sensitive password entered in the Password eld. For security,
each typed password character is masked with a dot (•).
Enable Password Change If the group user type is Captive Portal, enable password changes by user if needed.
MultiLogin
If the group user type is Captive Portal, enable MultiLogin allowing user using the same
username/ password login via multiple devices at the same time.

Table of Contents

Other manuals for D-Link DWC-2000

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the D-Link DWC-2000 and is the answer not in the manual?

D-Link DWC-2000 Specifications

General IconGeneral
Security algorithms802.1x RADIUS, WPA, WPA2
Data transfer rate1 Gbit/s
USB 2.0 ports quantity2
Ethernet LAN (RJ-45) ports4
Input voltage100 - 240 V
Input frequency50 - 60 Hz
Power consumption (typical)26.95 W
Storage temperature (T-T)-20 - 70 °C
Operating temperature (T-T)0 - 40 °C
Operating relative humidity (H-H)5 - 95 %
Compatible productsDWL-8610AP, DWL-8600AP, DWL-6600AP, DWL-3600AP, DWL-2600AP
CertificationFCC Class A, CE Class A, C-Tick, IC, cUL, LVD
Package depth504 mm
Package width444 mm
Package height110 mm
Package weight5846 g
Pallet width1200 mm
Pallet length1100 mm
Pallet height (air)1095 mm
Pallet height (sea)2055 mm
Pallet gross weight (air)250560 g
Quantity per pallet (air)36 pc(s)
Shipping (inner) case width396 mm
Shipping (inner) case height480 mm
Shipping (inner) case length526 mm
Shipping (inner) case weight18755 g
Shipping (inner) case net weight17538 g
Number of cartons per pallet (air)12 pc(s)
Quantity per shipping (inner) case3 pc(s)
Harmonized System (HS) code85176990
Weight and Dimensions IconWeight and Dimensions
Weight3720 g
Dimensions (WxDxH)440 x 310 x 44 mm
