D-Link DWC-2000 User Manual 66
Section 4 - Advanced WLAN Conguration
To congure Channel Algorithm setting:
1. Click Wireless > General > Power Algorithm > Power Setting tab.
2. You can congure the power as a percentage of maximum power, where the maximum power is the
minimum of power level allowed for the channel by the regulatory domain or the hardware capability.
Select Manual or Auto Mode.
3. Enter the power change threshold. The default value is -85dBm. The power changes are initiated only if
the neighbor radio hears the transmitting radio with the signal strength equal or above the threshold.
The signal detected below the threshold is ignored.
4. If you select Manual, click on the Manual Power Adjustments tab. Here you can apply and start the
power algorithm on selected access points.
Congure Power Settings
Path: Wireless > General > Power Algorithm
You can set the power of the AP radio frequency transmission in the AP prole, the local database or in the
RADIUS server. The power level in the AP prole is the default level for the AP, and the power will not be adjusted
below the value in the AP prole. The settings in the local database and RADIUS server always override power
set in the prole setting. If you manually set the power, the level is xed and the AP will not use the automatic
power adjustment algorithm.
