Section 5 - Advanced Network Conguration
Congure Flow-based Control
Path: Network > QoS > QoS Policy > Flow Control
The Flow-Based QoS Policy allows you to limit the Bandwidth for a particular service. Changes here aect the
trac of a congured service that is egressed on the ports.
1. Go to Network > QoS > QoS Policy > Flow Control tab.
2. Click Add New Flow-based Control QoS.
3. Complete the elds in the table below and click Save.
Field Description
Prole Name The name of the prole.
Service
Select the type of service you want to use. The choices are:
Any, aim, bgp, bootp_client, bootp_server, cu-seeme udp, cu-seeme tcp, dns udp,
dns tcp, nger, ftp, http, https, icmp, icq, imap2, imap3, irc, news, nfs, nntp, ping,
pop3, pptp, rcmd, rea-audio, rexec, rlogin, rtelnet, rtsp tcp, rtsp udp, sftp, smtp, snmp
tcp, snmp udp, snmp-traps tcp, snmp-traps udp, sql-net, ssh tcp, ssh udp, strmworks,
tacacs, telnet, tftp, rip, kie, shttpd, ipsec-udp-encap, ident, vddolive, ssh, sip-tcp, sip-
udp, or icmpv6.
Source IP Address The source IP address
Destination IP Address The destination IP address
Bandwidth Limit the Bandwidth for a particular service.
