D-Link DWC-2000 User Manual

D-Link DWC-2000 User Manual 234
Section 7 - Viewing Status and Statistics
Blocked WDS Link Count
Number of WDS links blocked by the spanning tree protocol. If the AP on
one side of the link reports the link as blocking then the link is counted by
this status parameter.
WDS Group Password Change Status
Status of the last attempt to congure the password for the WDS Group:
• Not Started
• Success
• Invalid Password
• Requested
• Timed Out
Edit Password
To change the password for all controllers and APs in this WDS Group, select
the Edit checkbox, type the new password, and then click Apply Password.
Password must be minimum of 8 characters and can be up to 63 characters
in length.

D-Link DWC-2000 Specifications

General

Security algorithms	802.1x RADIUS, WPA, WPA2
Data transfer rate	1 Gbit/s
USB 2.0 ports quantity	2
Ethernet LAN (RJ-45) ports	4
Input voltage	100 - 240 V
Input frequency	50 - 60 Hz
Power consumption (typical)	26.95 W
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Compatible products	DWL-8610AP, DWL-8600AP, DWL-6600AP, DWL-3600AP, DWL-2600AP
Certification	FCC Class A, CE Class A, C-Tick, IC, cUL, LVD
Package depth	504 mm
Package width	444 mm
Package height	110 mm
Package weight	5846 g
Pallet width	1200 mm
Pallet length	1100 mm
Pallet height (air)	1095 mm
Pallet height (sea)	2055 mm
Pallet gross weight (air)	250560 g
Quantity per pallet (air)	36 pc(s)
Shipping (inner) case width	396 mm
Shipping (inner) case height	480 mm
Shipping (inner) case length	526 mm
Shipping (inner) case weight	18755 g
Shipping (inner) case net weight	17538 g
Number of cartons per pallet (air)	12 pc(s)
Quantity per shipping (inner) case	3 pc(s)
Harmonized System (HS) code	85176990

Weight and Dimensions

Weight	3720 g
Dimensions (WxDxH)	440 x 310 x 44 mm
