Section 5 - Advanced Network Conguration
2. Complete the elds in the table below and click Save.
Field Description
IP Address Setup
IP Address LAN interface IP address of the wireless controller.
Subnet Mask The factory default: 255.255.255.0.
DHCP Setup
DHCP Mode
There are three DHCP modes to choose from:
• None: the controller’s DHCP server is disabled for the LAN
• DHCP Server. With this option the controller assigns an IP address within the
specied range plus additional specied information to any LAN device that
requests DHCP served addresses.
• DHCP Relay: With this option enabled, DHCP clients on the LAN can receive IP
address leases and corresponding information from a DHCP server on a dierent
subnet. Specify the Relay Gateway, and when LAN clients make a DHCP request
it will be passed along to the server accessible via the Relay Gateway IP address.
Domain Name Enter a domain name.
Starting IP Address
If DHCP mode = DHCP Server:
Enter the rst IP address in the range. Any new DHCP client joining the LAN will be
assigned an IP address between this address and the Ending IP Address.
Ending IP Address
If DHCP mode = DHCP Server:
Enter the last IP address in the range of addresses to lease to LAN hosts. Any new
DHCP client joining the LAN will be assigned an IP address between the Starting IP
Address and this IP address.
Default Gateway If DHCP mode = DHCP Server: Enter the default gateway.
Gateway If DHCP mode= DHCP Relay. Enter the relay gateway address.
Default Route
Enable Default Route Enable or disable (ON=enabled) the default route function.
Gateway If Enable Default Route=ON, enter the Gateway IP address.
DNS Server If Enable Default Route= ON, enter the DNS Server IP address.
SNAT
Enable or disable SNAT (Source Network Address Translation). Enable SNAT if you
have set up VLANs on your LAN network and it needs NAT to translate the source and
origin address.
DNS Host Name Mapping
Host Name Enter a DNS host name.
IP Address Enter the IP address of the DNS host name.
LAN Proxy
Active DNS Proxy
Enable or disable DNS proxy on this LAN.
When this feature is enabled, the controller will act as a proxy for all DNS requests
and communicate with the ISP’s DNS servers (as congured in the Option settings
page). All DHCP clients will receive the Primary/Secondary DNS IP along with the IP
where the DNS Proxy is running, i.e. the box’s LAN IP. All DHCP clients will receive the
DNS IP addresses of the ISP excluding the DNS Proxy IP address when it is disabled.
The feature is particularly useful in Auto Rollover mode. For example, if the DNS
servers for each connection are dierent, then a link failure may render the DNS
servers inaccessible. However, when the DNS proxy is enabled, then clients can make
requests to the controller and in turn, sends those requests to the DNS servers of the
active connection.

D-Link DWC-2000 Specifications

General

Security algorithms	802.1x RADIUS, WPA, WPA2
Data transfer rate	1 Gbit/s
USB 2.0 ports quantity	2
Ethernet LAN (RJ-45) ports	4
Input voltage	100 - 240 V
Input frequency	50 - 60 Hz
Power consumption (typical)	26.95 W
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Compatible products	DWL-8610AP, DWL-8600AP, DWL-6600AP, DWL-3600AP, DWL-2600AP
Certification	FCC Class A, CE Class A, C-Tick, IC, cUL, LVD
Package depth	504 mm
Package width	444 mm
Package height	110 mm
Package weight	5846 g
Pallet width	1200 mm
Pallet length	1100 mm
Pallet height (air)	1095 mm
Pallet height (sea)	2055 mm
Pallet gross weight (air)	250560 g
Quantity per pallet (air)	36 pc(s)
Shipping (inner) case width	396 mm
Shipping (inner) case height	480 mm
Shipping (inner) case length	526 mm
Shipping (inner) case weight	18755 g
Shipping (inner) case net weight	17538 g
Number of cartons per pallet (air)	12 pc(s)
Quantity per shipping (inner) case	3 pc(s)
Harmonized System (HS) code	85176990

Weight and Dimensions

Weight	3720 g
Dimensions (WxDxH)	440 x 310 x 44 mm
