D-Link DWC-2000 User Manual

D-Link DWC-2000 User Manual 125
Section 5 - Advanced Network Conguration
3. Complete the elds from the table below.
4. Click Save.
Field Description
IPv6 Prex Type Select the prex type as 6to4 or Global/Local/ISATAP.
SLA ID
If Ipv6 Prex Type= 6to4, the SLA ID (Site-Level Aggregation Identier) in the 6to4
address prex is set to the interface ID of the interface on which the advertisements
are sent.
IPv6 Prex If IPv6 Prex Type= Global / Local / SATAP, then denes the IPv6 network address.
IPv6 Prex Length
If Ipv6 Prex Type= Global/ Local/ SATAP, and this is a numeric value that indicates the
number of contiguous, higher order bits of the address that make up the network
portion of the address.
Prex Lifetime The length of time over which the requesting controller is allowed to use the prex.

D-Link DWC-2000 Specifications

General

Security algorithms	802.1x RADIUS, WPA, WPA2
Data transfer rate	1 Gbit/s
USB 2.0 ports quantity	2
Ethernet LAN (RJ-45) ports	4
Input voltage	100 - 240 V
Input frequency	50 - 60 Hz
Power consumption (typical)	26.95 W
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Compatible products	DWL-8610AP, DWL-8600AP, DWL-6600AP, DWL-3600AP, DWL-2600AP
Certification	FCC Class A, CE Class A, C-Tick, IC, cUL, LVD
Package depth	504 mm
Package width	444 mm
Package height	110 mm
Package weight	5846 g
Pallet width	1200 mm
Pallet length	1100 mm
Pallet height (air)	1095 mm
Pallet height (sea)	2055 mm
Pallet gross weight (air)	250560 g
Quantity per pallet (air)	36 pc(s)
Shipping (inner) case width	396 mm
Shipping (inner) case height	480 mm
Shipping (inner) case length	526 mm
Shipping (inner) case weight	18755 g
Shipping (inner) case net weight	17538 g
Number of cartons per pallet (air)	12 pc(s)
Quantity per shipping (inner) case	3 pc(s)
Harmonized System (HS) code	85176990

Weight and Dimensions

Weight	3720 g
Dimensions (WxDxH)	440 x 310 x 44 mm
