D-Link DWC-2000 User Manual

D-Link DWC-2000 User Manual 194
Section 7 - Viewing Status and Statistics
Path Description Page
Status> Wireless Information> Access
Point > > All APs
Shows summary information about managed, failed, and rogue
access points the wireless controller has discovered or detected.
213
Status > Wireless Information > Access
Point > Managed
Shows details about the managed access points. 214
Status > Wireless Information > Access
Point > Peer Managed
Shows information about the access points that each peer controller
in the cluster manages.
216
Status > Wireless Information > Access
Point > Authentication Failed
Shows information about access points that failed to establish
communication with the wireless controller.
217
Status > Wireless Information > Access
Point > RF Scan
Shows information about other access points and wireless clients
that the managed AP has detected.
218
Status > Wireless Information > Access
Point > De-Authentication Attacks
Shows information about rogue APs that the Cluster Controller has
attacked by using the de-authentication attack feature.
219
Status > Wireless Information > Access
Point > Hardware Capability
Shows information about radio hardware and IEEE mode supported
by access points, along with software images available for
downloading to access points.
221
Status > Wireless Information >
Associated Clients > Global Status
Shows statistics about all the clients’ trac while the clients are
associated with managed access points as well as throughout the
roaming session.
223
Status > Wireless Information >
Associated Clients > Associated Clients
Shows information about all the clients connected through managed
access points.
224
Status > Wireless Information >
Associated Clients > Ad Hoc Clients
Shows information about all ad-hoc clients. 228
Status > Wireless Information >
Associated Clients > Detected Clients
Shows information about clients that have authenticated with
an access point, and clients that disassociate and are no longer
connected to the system.
229
Status > Wireless Information >
Clustering
Shows information about other wireless controllers in the network. 231
Status > Wireless Information> WDS
Groups Status
Shows the summary information about congured WDS links 232
Status> Wireless Information> WDS
Group Status > WDS Group AP Status
Shows WDS group AP status congured APs and links in the WDS
Group.
233
Status > Wireless Information> WDS
Group Status> WDS AP Status
Shows the status of congured APs and links in the WDS Group. 235
Status > Wireless Information> WDS
Group Status> WDS Link Status
Shows WDS links in the WDS Group. 236
Status > Wireless Information> WDS
Group Status> WDS Link Statistics
Shows the statistic WDS links in the WDS Group. 237

D-Link DWC-2000 Specifications

General

Security algorithms	802.1x RADIUS, WPA, WPA2
Data transfer rate	1 Gbit/s
USB 2.0 ports quantity	2
Ethernet LAN (RJ-45) ports	4
Input voltage	100 - 240 V
Input frequency	50 - 60 Hz
Power consumption (typical)	26.95 W
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Compatible products	DWL-8610AP, DWL-8600AP, DWL-6600AP, DWL-3600AP, DWL-2600AP
Certification	FCC Class A, CE Class A, C-Tick, IC, cUL, LVD
Package depth	504 mm
Package width	444 mm
Package height	110 mm
Package weight	5846 g
Pallet width	1200 mm
Pallet length	1100 mm
Pallet height (air)	1095 mm
Pallet height (sea)	2055 mm
Pallet gross weight (air)	250560 g
Quantity per pallet (air)	36 pc(s)
Shipping (inner) case width	396 mm
Shipping (inner) case height	480 mm
Shipping (inner) case length	526 mm
Shipping (inner) case weight	18755 g
Shipping (inner) case net weight	17538 g
Number of cartons per pallet (air)	12 pc(s)
Quantity per shipping (inner) case	3 pc(s)
Harmonized System (HS) code	85176990

Weight and Dimensions

Weight	3720 g
Dimensions (WxDxH)	440 x 310 x 44 mm
