D-Link DWC-2000 User Manual 41
Section 3 - Basic Conguration
c. Select a user type from the drop-down menu next to Captive Portal Type. Choosing Free will allow
immediate access through the Captive Portal; choosing SLA will require the end user to agree to
a service level agreement before being allowed access. Choosing Permanent User will allow for
selecting an authentication method such as local user database, RADIUS, LDAP, or POP3. Choosing
Temporary User or Billing User the authentication method is local user database.
In this case, the user account in the local database is a permanent user account. Select Permanent
User on Captive Portal Type and select Local User Database on Authentication Server.
d. Select the customized login page from the Login Prole Name drop-down menu.
e. Click Save.
The captive portal is now associated to the selected SSID. To test your conguration from a client, connect to the
captive portal SSID to log in to the captive portal. Enter an IP address on the captive portal network to see the
controller redirect request to the captive portal page.
If the authentication database is using the RADIUS server, on step c above choose Permanent User on Captive
Portal Type and select RADIUS Server on Authentication Server.
4. Customize the captive portal login page.
a. Go to Security > Authentication > Login Proles. The Login Proles page will appear.
