D-Link DWC-2000 User Manual 92
Section 4 - Advanced WLAN Conguration
Field Description
Multicast Tx Rate (Mbps)
Select the 802.11 rate at which the radio transmits multicast frames. The rate is in Mbps.
The lowest rate in the 5 GHz band is 6 Mbps.
Channel
Auto Eligible Channels
This eld displays the channels that are supported for the radio mode currently selected
on the page and for the country congured on the General Settings page. Press Crtl to
select multiple channels.
Basic Rate Set (Mbps)
These numbers indicate the data rates that all stations associating with the AP must
support.
Supported Rate Set (Mbps)
These numbers indicate rates that the access point supports. You can select multiple
rates. The AP automatically chooses the most ecient rate based on factors like error
rates and distance of client stations from the AP.
