D-Link DWC-2000 User Manual

D-Link DWC-2000 User Manual 99
Section 4 - Advanced WLAN Conguration
3. Complete the elds in the table below and click Save.
Field Description
SSID
Enter a name of your wireless network. Be sure SSID is the same for all device in your
wireless network and is case-sensitive.
Captive Portal Type
Captive Portal type is selected per SSID basis. There are four types of access on a SSID:
• Free: No authentication is required for users connected to this SSID if this option is
selected.
• SLA (Service Level Agreement): If this is selected, users connected to this SSID needs
to accept Service Level Agreement before accessing anything outside this SSID.
• Permanent User: When this option is selected users need to get authenticated before
accessing data outside this SSID. Only permanent Captive Portal users can login from
this SSID.
• Temporary User: When this option is selected users need to get authenticated before
accessing data outside this SSID. Only temporary Captive Portal users created by
frontdesk user can login from this SSID.
• Billing User: When this option is selected users need to get authenticated before
accessing data outside this SSID. The temporary Captive Portal billing users created
via online wireless service purchasing. The wireless service packages are dened in
Login Prole.
Authentication Server
If Captive Portal Type = Permanent User, select the authentication server.
All users that log in to the captive portal for this SSID are authenticated through the
selected server. The available authentication servers are Local User Databass, Radius
Server, LDAP Server, or POP3.
Authentication Type
If Captive Portal Type = Permanent User and Authentication Server = RADIUS server,
select the authentication type: PAP, CHAP, MSCHAP, or MSCHAPV2.
Login Prole Name
If Captive Portal Type = Permanent User or Temporary User, select the Login Prole.
Any of the available proles can be used for this SSID.
Hide SSID
You can hide the SSID broadcast to discourage stations from automatically discovering
your access point(s). When the broadcast SSID of the AP is hidden, the SSID name is not
displayed in the list of available SSID on a client station. Instead, the client must have the
exact SSID name congured in the supplicant before it is able to connect.
Disabling the broadcast SSID is sucient to prevent clients from accidentally connecting
to your network, but it will not prevent even the simplest of attempts by a hacker to
connect or monitor unencrypted trac.
ON = SSID is hidden
OFF = SSID is broadcast

D-Link DWC-2000 Specifications

General

Security algorithms	802.1x RADIUS, WPA, WPA2
Data transfer rate	1 Gbit/s
USB 2.0 ports quantity	2
Ethernet LAN (RJ-45) ports	4
Input voltage	100 - 240 V
Input frequency	50 - 60 Hz
Power consumption (typical)	26.95 W
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Compatible products	DWL-8610AP, DWL-8600AP, DWL-6600AP, DWL-3600AP, DWL-2600AP
Certification	FCC Class A, CE Class A, C-Tick, IC, cUL, LVD
Package depth	504 mm
Package width	444 mm
Package height	110 mm
Package weight	5846 g
Pallet width	1200 mm
Pallet length	1100 mm
Pallet height (air)	1095 mm
Pallet height (sea)	2055 mm
Pallet gross weight (air)	250560 g
Quantity per pallet (air)	36 pc(s)
Shipping (inner) case width	396 mm
Shipping (inner) case height	480 mm
Shipping (inner) case length	526 mm
Shipping (inner) case weight	18755 g
Shipping (inner) case net weight	17538 g
Number of cartons per pallet (air)	12 pc(s)
Quantity per shipping (inner) case	3 pc(s)
Harmonized System (HS) code	85176990

Weight and Dimensions

Weight	3720 g
Dimensions (WxDxH)	440 x 310 x 44 mm
