EX50-SA / EX55-SA / EX5310-AU / EX5810-AU
(1) Brake Pedal (LH) (2) Brake Pedal (RH)
(3) Interlock
(A) Engage (B) Disengage
4. Make sure the brake pedal of the
left and right side is engaged.
If depressing only one brake
pedal at a high speed, the trac-
tor can lose its balance and be
off the track.
WARNING
5. Pull the position control lever back-
ward to raise the attachment.
6. Increase slowly the engine RPM
from idle speed to medium speed.
(1) Position Control Lever
(A) Lifting
T46O523A
(1) Hand Throttle Lever (2) Foot Throttle
INCREASE DECREASE
T46O564A
TE5O416A
