Daedong EX50-SA - Shuttle Shift Lever; Pto Shift Lever

4
DESCRIPTION OF OPERATING SYSTEM
4
-
21
SHUTTLE SHIFT LEVER
(1) Shuttle Shift Lever
(F) Forward (R) Reverse
(N) Neutral
This lever is used to select forward
or reverse driving. The lever can be
shifted while the tractor is moving
with the clutch disengaged as these
gears are synchromesh. Shifting this
lever frequently can deteriorate the
trans-mission’s life and durability.
Put this lever into the N position
(Neutral) when the tractor is not driv-
en.
TE5O409A
•
Reduce the speed before mov-
ing this lever since it is very
dangerous to switch the driv-
ing direction at a high speed.
CAUTION
PTO SHIFT LEVER
This lever is to shift the PTO speed
into 3 speeds.
Shift
Model
1st 2nd 3rd
ALL 540 750 1,000
(rpm)
TE5O410A
(1) PTO Shift Lever
