Daedong EX50-SA - INSTRUMENT PANEL

4
DESCRIPTION OF OPERATING SYSTEM
4
-
13
INSTRUMENT PANEL
Symbols on the instrument panel come on when the key switch is turned to
the "ON" position.
TACHOMETER / HOURMETER
(1) PTO Operating Indicator
(2) Headlight-High Beam Lamp
(3) Battery Charging Warning Lamp
(4) Parking Brake Lamp
(5) Glow Plug Indicator
(6) Left Turn Indicator
(7) Tachometer
(8) Right Turn Indicator
(9) Engine Oil Pressure Warning Lamp
(10) Front Wheel Drive Indicator
(11) Fuel Gauge
(12) Hour-Meter Indicator
(13) Coolant Temperature Gauge
(1) Tachometer (2) Hourmeter
TE5O422A
T46O567A
The tachometer indicates the engine
speed and the 540rpm PTO operat-
ing speed.
The hour-meter indicates, in five
digits, the hours that the tractor has
been operated.
