Daedong EX50-SA - Replacing Bulb(Aq)

EX50-SA / EX55-SA / EX5310-AU / EX5810-AU
7
-
36
•
Using a non-approved slow-
blow fuse can damage elec-
trical systems in the tractor
severely.
•
Refer to the chapter "Trouble-
shooting" in this manual
or contact your local KIOTI
Dealer for specic information
dealing with electrical prob-
lems.
IMPORTANT
The bulb and capacity used in this
tractor are listed in the below table.
This section only describes proce-
dures the users can handle.
REPLACING BULB(AQ)
No. Bulb Capacity
1 Headlamp 55W/60W
2 Stop/Position lamp (Rear) 21W/5W
3 Turn signal lamp 21W
4 Work lamp 21W
5
Cluster
Charging
warning light
3W
Indicator Others 1.4W
HEADLAMP
(1) Handle
(A) Pull (B) Open
1. Turn the key switch to the "OFF"
position and open the hood.
TE5O709A
