DESCRIPTION OF OPERATING SYSTEM
4
-
29
•
Be extra careful not to let any
part of your body under the
tractor or an implement when
lowering an implement.
WARNING
POSITION CONTROL LEVER
(1) Position Control Lever
(A) Lifting
T46O523A
The position control lever is used
to keep the plowing depth constant
during work.
The implement attached to the lifting
arm can be lowered by pushing the
lever while the implement is raised
by pulling the lever.
In order to limit the lowering height of
implements, use the lock bolt (2) to
limit the operating range of the lever.
For detailed information, refer to "Ini-
tial Operation" in Chapter 5.
•
Make sure that there is no-
body or not obstacle around
the three-point linkage before
controlling position lever.
WARNING
