(1) Position Control Lever (2) Lock Bolt
7. The lower limit of the implement’s
lowering height can be set by limit-
ing the movement of the lever by
the lock bolt.
T46O704A
If trying to lift an object with
excessive weight by the
3-point hitch while the tractor
is not equipped with proper
front suit case weights, the
front wheels may be lifted
instead, leading to roll over.
Make sure to follow the speci-
cations for use.
WARNING
DRAFT CONTROL
(1) Draft Control Lever
1. The draft control function is used
to prevent the wheels from rotating
idle and the engine from stopping
due to excessive draft load when
the tractor is used for work which
requires a lot of draft, such as
plowing.
T46O702A
