Daedong EX50-SA - Page 49

3
SPECIFICATIONS
3
-
5
※
The specications are subject to change without notice.
ITEM
MODEL
EX50-SA EX55-SA EX5310-AU EX5810-AU
Hydraulic
Lift Capacity
@ 24 in. behind lift point kgf (lbs) 1,131 (2,493)
@lift point kgf (lbs) 1,334 (2,940)
No.of standard remote valves (Rear) 2
PTO
Rear
Type Independent
PTO shaft specications
SAE 1-3/8, 6
spline
1 / 2 / 3 stages rpm 540 / 750 / 1,000
Min. turning radius (With one rear wheel braked) m (ft) 3.04 (9.97)
Weight with ROPS and AG tires kgf (lbs) 1,790 (3,946) 1,795 (3,957) 1,790 (3,946) 1,795 (3,957)
Max. Draw-bar vertical load kgf (lbs)
735 (1,620)
Max. Trailer loading weight kgf (lbs) 4,700 (10,361)
TE150 (EX50, EX55)-���-03.indd 5 2019-03-19 �� 4:29:19
