Dahua DHI-NVR608R-64-4KS2 User Manual

165
Figure 3-154
2. In the fisheye window, click any point or move
to confirm the position.
3. In the PTZ window, click the ions under the window to adjust the PTZ position to make the
center of PTZ window the same as the position
locates in the fisheye window. For icon
description, see the following table.
Note
indicates the center of the PTZ window.
Icon Description
、
Control the PTZ to zoom in and zoom out.
、
Adjust the definition of the PTZ image.
、
Adjust the brightness of the PTZ image.
Electronic mouse. Move the mouse on the interface to control the PTZ
direction.
Quick positioning. Click this icon, select any position on the screen and
the image automatically adjust centered on the selected point.

Dahua DHI-NVR608R-64-4KS2 Specifications

General

Model	DHI-NVR608R-64-4KS2
Operating System	Embedded LINUX
IP Camera Input	64 channels
Two-way Talk	Yes
OSD	Yes
Video Detection and Alarm	Yes
Wireless	No
USB	2 x USB 2.0
Operating Humidity	10% to 90% (non-condensing)
Video Compression	H.265+/H.265/H.264+/H.264
Video Output	HDMI, VGA
Alarm input	16 channel
Relay Output	4
Ethernet	2 RJ-45 port (10/100/1000Mbps)
Internal HDD	8 SATA interfaces, up to 10TB each
eSATA	1
RS232	1
RS485	1
Power Supply	AC 100-240V, 50/60Hz
Operating Temperature	-10°C to +55°C
Dimension	440mm
Weight	6.5 kg
