Dahua DHI-NVR608R-64-4KS2 User Manual

56
Step 4 Click Apply button to save schedule record settings.
Note
Please enable auto record function so that the record plan can become activated.
3.4.6.2 Schedule Snapshot
It is to set schedule snapshot period.
After set schedule snapshot, device can snapshot image according to the period you set here. For
example, the alarm snapshot period is from 6:00～18:00 Monday, device can snapshot during the 6:00～
18:00 when an alarm occurs.
Step 1 Click Snapshot button, device goes to following interface. See Figure 3-31.
Note
From main menu > Setting > Storage > Schedule > Snapshot, you can go to the snapshot
interface.
Figure 3-31
Step 2 Select a channel to set schedule snapshot.
Step 3 Set snapshot type as schedule.

Dahua DHI-NVR608R-64-4KS2 Specifications

General

Model	DHI-NVR608R-64-4KS2
Operating System	Embedded LINUX
IP Camera Input	64 channels
Two-way Talk	Yes
OSD	Yes
Video Detection and Alarm	Yes
Wireless	No
USB	2 x USB 2.0
Operating Humidity	10% to 90% (non-condensing)
Video Compression	H.265+/H.265/H.264+/H.264
Video Output	HDMI, VGA
Alarm input	16 channel
Relay Output	4
Ethernet	2 RJ-45 port (10/100/1000Mbps)
Internal HDD	8 SATA interfaces, up to 10TB each
eSATA	1
RS232	1
RS485	1
Power Supply	AC 100-240V, 50/60Hz
Operating Temperature	-10°C to +55°C
Dimension	440mm
Weight	6.5 kg
