300
Parameter Description
Period
Enter the period only in which the system triggers the linked alarms.
1. Click Setup and the Period interface is displayed.
2. Configuer the period.
Method 1: Press and hold down the left button of the mouse and
drag it on the screen to set it directly.
Method 2: Click the Setup corresponding to the weekday, select the
check box in front of the period, and then enter the time. You can
set six periods for each day.
3. Click OK to complete the setting.
Step 4 Click OK to complete the setting.
After the setting, the effect is displayed as follows. See Figure 4-61.
Figure 4-61
4.6.4 Event
4.6.4.1 Video detect
4.6.4.1.1 Motion Detect
After analysis video, system can generate a video loss alarm when the detected moving signal reached
the sensitivity you set here.
From main window>Setup>Event>Video detect>Motion detect, the motion detect interface is shown as in
Figure 4-62.
