292
Parameter Description
Temp error
The error of alarm threshold. If the alarm threshold or temp slope changes
within the error range, system deals it as a value meeting the threshold.
The range is from -10℃ to +10℃.
Temp lasting
time
The time that the temp or temp change lasts. The range is from 0s to
1000s.
Step 3 Click OK to complete the setting.
Step 4 After the setting, you can view the temp of the rule on the preview interface on the left of the
window.
4.6.3.2.2 Temp Comprison
Compare the temp of the selected spot, line and zones and display the results on the preview interface.
You shall set at least two temp measurement rules first. For details, see 4.6.3.2.1 Temp Rule.
Step 1 Select Setup > Temperature Measurement > Rule > Temp Comprison.
The Temp Comprison interface is displayed.
Step 2 Set the temp comparison rule.
1. Click
to add comprison rule.
The Add interface is displayed. See Figure 4-54
Figure 4-54
2. Select the comparison object.
3. Set the alarm parameters. For details, see the following table.
Parameter Description
Alarm Result
Approaches to obtain the temp for alarm activation.
Average temp: Compare the average temp of the two objects.
Highest temp: Compare the highest temp of the two objects.
Lowest temp: Compare the lowest temp of the two objects.
Note
