326
Button Function
It is to control PTZ movement speed. The higher the
value is, the faster the speed is.
For example, the step 8 speed is faster than step 1.
Click add button and then click to save.
Now you complete one group position, you can view at the list. See Figure 4-100.
Figure 4-100
Repeat the above steps to set at least three group positions.
Note
For one PTZ camera, there must be three calibration groups. System max supports 8 group positions.
Please make sure the calibration position is accurate.
For the first calibration group position, please select the reference objects at the far distance to
enhance the trigger accuracy.
Click OK button to complete the calibration setup, you can go back to the smart track interface, the status
is shown as
.
4.6.4.9 Alarm
Before operation, please make sure you have properly connected alarm devices such as buzzer. The
input mode includes local alarm, network alarm, and IPC external alarm and IPC offline alarm.
4.6.4.9.1 Local Alarm
From main menu>Setup>Event>Alarm>Local alarm, the local alarm interface is shown as in Figure 4-101.
It refers to alarm from the local device.
